Specifition:
Nominal Diameter: 152/6 mm/in
Nominal Impedance: 8 Ω
Minimum Ipedance: 6.3 Ω
Power Handling: 60 W
Sensitivity (1w/1m): 97.1 dB
Frequency Range: 84 – 6000 Hz
Voice Coil Diameter: 35.5 mm
Voice Coil Material: EISV
Kind of Layer: Outside
Magnet Outer Diameter: 120 mm
Magnet Material: Ferrite
Overall Diameter: 168 mm
Baffle Cutout Diameter: 146 mm
Boit Circle Diameter: 158*4-Φ4.8
Flange and Gasket Thickness: 8 mm
Overall Depth: 88 mm
Net Weight: 2 Kg
