Specifition:
Nominal Diameter: 305/12 mm/in
Nominal Impedance: 8 Ω
Minimum Impedance: 5.2 Ω
Power Handling: 450 W
Sensitivity (1w/1m): 97.3 dB
Frequency Range: 55 – 2700 Hz
Voice Coil Diameter: 99.5 mm
Voice Coil Material: CCAW
Kind of Layer: Inside/Outside
Magnet Outer Diameter: 220 mm
Magnet Material: Ferrite
Overall Diameter: 313 mm
Baffle Cutout Diameter: 283 mm
Boit Circle Diameter: 295*8-Φ6.5
Flange and Gasket Thickness: 15 mm
Overall Depth: 122 mm
Net Weight: 9.8 Kg
