Specifition:
Nominal Diameter: 254/10 mm/in
Nominal Impedance: 16 Ω
Minimum Ipedance: 10.5 Ω
Power Handling: 300 W
Sensitivity (1w/1m): 93.5 dB
Frequency Range: 56 – 3000 Hz
Voice Coil Diameter: 75.5 mm
Voice Coil Material: CCAW
Kind of Layer: Outside
Magnet Outer Diameter: 180 mm
Magnet Material: Ferrite
Overall Diameter: 264 mm
Baffle Cutout Diameter: 231 mm
Boit Circle Diameter: 246*8-Φ6.5
Flange and Gasket Thickness: 15 mm
Overall Depth: 120 mm
Net Weight: 4.2 Kg
